Standard: GB 8181-2005 "fire hose" standard.

Nozzle body material: 6061 aluminum alloy

Forging process: five-axis machining center one milling shape.

Material of handle: PA6 nylon plastic.

Material of valve stem: brass.

Material of valve ball: precision machining brass, chrome-plated surface.

Ball seal material: PTFE seal ring high temperature sintering.

Fixing screw material: stainless steel or copper.

Water gun protective sleeve material: nitrile rubber.

Water gun sealing ring: wear-resistant anti-aging rubber.

Material of spray rotating teeth: forged brass, chrome-plated treatment.

Surface treatment: overall anodized anti-corrosion.

Water inlet interface: card type KYKA65Z male forged interface with thread locking structure.

Operating lever: ∩ type, control water flow switch, with DC and full water mist mode.

Water inlet interface: 360-degree rotation to prevent the water belt twisted and knotted.

Rated injection pressure: 0.60MPa.

Water gun gear: 4 gears, flow rate gear range: 2.5/4/6.5/8 L/s X (1 ± 8%).

Range: 32m.

Spray angle adjustment range (°): 0 ~ 120. 19

Weight: 1.98kg.

Operating torque: 7.7 N.m.

Provide the inspection report issued by China National Fire Equipment Inspection Center.
